Ford 6r140 Helpful info

The Ford 6R140 transmission found in 11-19 6.7 Powerstrokes, a heavy-duty six-speed automatic transmission, was developed for Ford Super Duty trucks and was introduced in 2011. The 6R140 transmission is still in use and has earned a reputation for its ability to handle high torque and heavy loads, making it an ideal choice for towing and hauling applications.

The salient features of the Ford 6R140 transmission are:

1. Six-speed automatic: The 6R140 transmission is equipped with six speeds, resulting in smooth shifting and optimized fuel economy.

2. TorqShift technology: The 6R140 transmission is integrated with Ford's TorqShift technology, comprising a high-capacity pump and robust clutch packs, enhancing its durability and performance.

3. Tow/Haul mode: The 6R140 transmission is outfitted with a tow/haul mode that modifies shift points, resulting in improved towing and hauling performance.

4. SelectShift capability: The 6R140 transmission allows the driver to manually shift gears using the SelectShift feature, affording greater control when desired.

5. Integrated PTO provision: The 6R140 transmission features an integrated PTO (power take-off) provision, facilitating direct mounting of PTO units without requiring additional adapters.

Over the years, some common issues with the 6R140 transmission include valve body malfunction, torque converter issues, and lack of proper maintenance. Regular servicing at 75,000-mile intervals can mitigate these issues. In case of a harsh 2-3, 5-6 upshift or downshift, customers should first check the fluid/filter. If no debris is found, they should replace the valve body with an OEM Ford valve body. Regular servicing as recommended will significantly reduce any issues.

The 6R140 transmission is known to handle over 600 hp reliably for a protracted duration. Quality trans tuning is crucial. It is not uncommon for us to encounter issues with customers tuning, including random shift flares, harsh shifts, or harsh converter lockup.
